The Cisco 1941 Integrated Services Router (ISR) delivers highly secure data, mobility,            and application services. Key features include:

• 2 integrated 10/100/1000 Ethernet ports

• 2 enhanced High-Speed WAN Interface Card slots that can host 2 single wide or 1 double wide and 1 single wide (e)HWIC

• 1 Internal Services Module slot

• Fully integrated power distribution to modules supporting 802.3af Power over Ethernet (PoE) and Cisco Enhanced PoE

• Security

  • Embedded hardware-accelerated VPN encryption

  • Secure collaborative communications with Group Encrypted Transport VPN, Dynamic Multipoint VPN, or Enhanced Easy VPN

  • Integrated threat control using Cisco IOS Firewall, Cisco IOS Zone-Based Firewall, Cisco IOS IPS, and Cisco IOS Content Filtering

  • Identity management that uses authentication, authorization, and accounting (AAA), and public key infrastructure

Properties:

Modular Platform

●  The Cisco 1941 Series ISR are highly modular platforms with multiple module slots to provide connectivity and services for varied branch network requirements.

●  The ISRs offer an industry-leading breadth of LAN and WAN connectivity options through modules to accommodate field upgrades to future technologies without requiring replacement of the platform.

​

Processors

●  The Cisco 1941 Series is powered by high-performance multi-core processors that support growing demands of branch office networks by supporting high throughput WAN requirements.

​

MultiGigabit Fabric

●  The Cisco 1941 introduces an innovative MultiGigabit Fabric (MGF) which allows for efficient module to module communication, enabling direct services interactions across modules while reducing the overhead on the router processor.

​

Embedded IPSec VPN Hardware Acceleration

●  Embedded hardware encryption acceleration is enhanced to provide higher scalability, which, combined with an optional Cisco IOS Security license, enables WAN link security and VPN services (IPSec acceleration).

●  The onboard encryption hardware out-performs the Advanced Integration Modules of previous generations.

​

Integrated Gigabit Ethernet Ports

●  All onboard WAN ports are 10/100/1000 Gigabit Ethernet WAN routed ports.

​

Innovative universal-serial-bus (USB)-based console access

●  A new, innovative, mini-B USB console port supports management connectivity when traditional serial ports are not available.

●  The traditional console and auxiliary ports are also available. Either the USB-based console or the RJ-45-based console port can be used to configure the router.

Optional Integrated Power Supply for Distribution of Power Over Ethernet (PoE)

●  An optional upgrade to the internal power supply provides in-line power (802.3af-compliant Power-over-Ethernet [PoE] and Cisco standard inline power) to optional integrated switch modules.

​

Integrated Wireless LAN

●  The Cisco 1941 offers a secure integrated access point in a single device.

●  Integrated access point is based on the IEEE 802.11n draft 2.0 standard that uses MIMO (Multi-Input, Multiple-output) to improve coverage for existing 802.11a/b/g clients and new 802.11n clients.

●  The Cisco 1941 supports dual radios - 802.11 b/g/n and 802.11a/n and is capable of operating in both autonomous and unified modes.
